IT STARTS HERE
(RETRO EDITION)
ISSUE 33
MARCH 13 2011

Hi everyone,

A shout-out to emails of the 1990s!

Enjoy the neat animations below (forwarded to me via a chain email), and good luck with the last of the midterms/catching-up after midterms/everything else we're all doing :)

Yan



SUBJECT: PRINCIPLES FOR ENGINES

Simple animation to explain complex principles:

1: Aircraft Radial Engine
radial engine



2: Oval Regulation
oval regulation

3: Sewing Machines
sewing machines
4: Malta Cross movement - second hand movement used to control the clock
malta cross movement


5: Auto Change file mechanism
auto change file


6: Auto Constant Velocity Universal Joint
constant velocity joint


 7: Gun Ammunition loading system
ammunitionloading




8: Rotary Engine - an internal combustion engine, the heat rather than the piston movement into rotary movement

rotary engine
9: Inline Engine - it's cylinders lined up side by side

inline engine
